Basic Info.
Model NO.
LS202AK
Power
4kw
Power Fuel
Electric
Maximum Speed
>30 km/h
Gradeability
20-30%
Suitable for
Golf Course
Certification
CE
Voltage of Battery
72V
Color
White
Transport Package
Steel Crate
Specification
2 Seats
Trademark
Lexsong
Origin
China
HS Code
8703101900
Production Capacity
5000units/Year
Product Description
| System | 72V/4KW or 72V/5KW AC System |
| Battery | 72V/84AH Lithium Ion Battery (Optional 72V/126AH) |
| Motor | 4KW/5KW AC |
| Controller | 350A/450A AC Controller |
| Passenger Capacity | 2 |
| Range (loaded) based on flat road at speed of 20km/h | >100kms |
| Max.speed | 32km/h (adjustable) |
| Min.turning radius | 3.7m |
| Max.climbing ability (loaded) | 25% |
| Max.loading weight | 270kgs |
| Net weight | 420kgs |
| Overall Dimensions (LxWxH) | 2400*1210*1890mm |
| Frame | Welded steel framework with galvanization and powder coating |
| Body parts | Injected PP plastic front cover + rear cover |
| Roof | Injected PP plastic |
| Windshield | Tinted splited windshield |
| Upright and sweater basket and bracket | Carbon steel, galvanizted and powder coated |
| Backrest and seat cushion | Sponge+artificial leather cover |
| Floor | Anti-slip rubber |
| Center storage basket | Plastic, large |
| Golf Bag holder | Plastic |
| Steering wheel | With score board clipper |
| Side trim | Plastic |
| Side mirror | 2pcs, foldable |
| Lighting system and horn | Lights including headlight, turning light, brake lights, with DC converter, electric horn |
| Reverse buzzer | 12V |
| Charger | Onboard HF charger, input 100V-240V, output 72V/12A |
| Steering System | Single-stage rack and pinion steering system, automatic rocker compensating function |
| Brake system | 4 wheel hydraulic front disc rear drum brake, with park brake and Regen brake |
| Accelerator | Stepless speed change |
| Suspenson system | Front Independent suspension and rear leaf spring and shock absorber |
| Rear Axle | Integrated |
| Wheel&Tyre | 12x7 Aluminum rim & 215/35-12 4PR tubless tire |
